may result.
• Double-check
all wiring before turning ON the power supply.
• After
wiring, route the cable so that force is not applied directly to the
connections.
Bending Radius of Connecting Cables
• To prevent
damaging the Connecting Cables, use the following minimum bending radii as
guidelines.
Precautions for Correct Use
Appearance Model Cable length L (m)
XW2Z-C50X 0.5
XW2Z-100X 1
XW2Z-200X 2
XW2Z-300X 3
XW2Z-500X 5
XW2Z-010X 10
Cable length L (m)
Wiring Diagram
XG4M-2030-T
(Mating Side)
XG4M-2030-T
(Mating Side)
Triangle mark
Triangle mark
19 20
17 18
1 2
3 4
2 1
4 3
20 19
18 17
Note: Wire the pins 1:1 so that the
Connector pin numbers match. L
EE
B,BU,B-A,B-B,D,
K,L,N,PF,PM
H-1,H-2,H-3
83mm
88mm
99mm
Connecting Cables for I/O Terminal Blocks
XW2Z
Connect I/O Terminal Blocks (XW2@) to
I/O Units of Programmable Controllers.
Fast and Faultless.
Ratings and Specifications
*1 Contact resistance for the Connector.
*2 Dielectric strength for the Connector.
Materials and Finish
Note: These housings, contacts, and
connecting screws are made by Fujitsu Component, Ltd.
Rated current 1 A
Rated voltage 125 VAC 24 VDC
Contact resistance 20 mΩ max. (at 20 mV, 100 mA max.) *1
Insulation resistance 100 MΩ min. (at 500 VDC)
Dielectric strength 500 VAC for 1 min
(leakage current: 1 mA max.) *2
Ambient operating
temperature −25 to 80°C
Item Part name Materials and Finish
Connectors
MIL :
XG4M-2030
XG4M-4030
XG4M-6030
Housing Fiber-glass reinforced PBT resin
(UL94V-0)/black Cover
Contacts Mating end Phosphor bronze/nickel
base, 0.15-μm gold
plating
Press-fit end Phosphor bronze/nickel base,
2.0-μm tin plating
XG4T-2004/4004/6004 Strain Relief
Fiber-glass reinforced PBT resin (UL94V-0)/black
FCN-367J024-AU/FW *
FCN-367J040-AU/FW
FCN-367J056-AU/FW
Housing Polyester resin (UL94V-0)/black
Contacts Mating end Copper alloy/gold
plated
Press-fit end Copper alloy/tin plated
Connecting screw Steel/nickel plated
Cable UL2464 Interface Cable AWG28 or the
equivalent/AWG28 Non-shield
XW2Z
